Hp 8901B modulation analyzer / opt 001 and 003
For Sale: Hp 8901B modulation analyzer / opt 001 and 003
Subject Hp 8901B modulation analyzer / opt 001 and 003
Ad is submitted by poster:
Measures AM and FM to 1% accuracy
Frequency Range: 150 kHz to 1300 MHz
Operating Level: 12 mV rms to 7 V rms
Tuning: Manual frequency entry, automatic, or track
Acquisition Time (automatic operation): ~1.5 s
Maximum Safe Input Level (typical): 35 V rms (25 W for source
±2% of reading ±1 digit, 20 Hz to 10 kHz rates, 250 kHz to 10 MHz;
±1% of reading ±1 digit, 50 Hz to 100 kHz rates, 10 to 1300 MHz
Demodulated Output Distortion: <0.1% THD
AM Rejection (for 50% AM at 400 Hz and 1 kHz rates): <20 Hz peak
Deviation measured in a 50 Hz to 3 kHz BW
Residual FM (50 Hz to 3 kHz BW): <8 Hz rms @ 1300 MHz, decreasing linearly with frequency to <1 Hz rms for 100 MHz and below
Maximum Deviation Resolution: 1 Hz
Stereo Separation (50 Hz to 15 kHz): >47 dB typical
Carrier Frequency: 10 to 1300 MHz
Rates: 200 Hz to 20 kHz; typically usable from 20 Hz to 100 kHz with degraded performance
Maximum Deviation Resolution: 0.001 radian
Accuracy: ±3% of reading ±1 digit
Demodulated Output Distortion: <0.1% THD
AM Rejection (for 50% AM at 1 kHz rate): <0.03 radian peak deviation
±2% of reading ±1 digit, 50 Hz to 10 kHz rates, 150 kHz to 10 MHz;
±1% of reading ±1 digit, 50 Hz to 50 kHz rates, 10 to 1300 MHz
Flatness (variation in indicated AM depth for constant depth on input(signal): ±0.3% of reading ±1 digit
Demodulated Output Distortion: <0.3% THD
FM Rejection (at 400 Hz and 1 kHz rates, 50 Hz to 3 kHz BW): <0.2% AM
Residual AM (50 Hz to 3 kHz BW): <0.01% rms
Maximum Depth Resolution: 0.01%
Accuracy: ±3 counts of least significant digit ± reference accuracy
Excellent Physcial/Excellent Working
Guaranteed with 5 day Right of Refusal
This unit has been completely tested with a signal generator for frequency, fm, am, and rf power. It is in excellent working and physical condition. This unit has Opt 001 and 003.
Contact us at noemi_strickland@repair--parts.com with any questions.
This item is quaranteed with a 5 day right of refusal. In the unlikely event that your unit arrives not as described, it will be replaced at no charge. If there is no exchange unit available, you will be given a full refund.
