Tek S4 svc/ops manual in dual resolutions txtsearch s-4
For Sale: Tek S4 svc/ops manual in dual resolutions txtsearch s-4
Subject Tek S4 svc/ops manual in dual resolutions txtsearch s-4
Ad is submitted by poster:
Tektronix S4 Service/Ops Manual in both Very High and in Normal Resolution PDF on CD
Why settle for just one resolution? You get them both!
For High Res page samples from this specific manual, click HERE.
(No need to "email for samples," so no need to worry about getting sold to a SPAM list!)
(Please read FAQ or "About Me" Page)
All manuals (though not all application notes) we distribute are editable.
These PDFs contain NO shareware begging, source identification, or other self-serving letters!
There are NO military manuals added to "beef up" the "volume count"!
This manual (070-0896-00) covers the Tektronix S4 Sampling Head. It is scanned from the original manufacturer's manual. The scans came out well, and all information available in the original manual is available here.
Two PDFs of the manual are provided, in two resolutions. One is:
Text with Drawings at 600dpi black and white
Schematics at 600dpi black and white
Text with photos at 600dpi grayscale with contrast adjusted
Schematics, board overlays that have color notes at 600dpi 256 colors
This resolution looks nice, but for many purposes uses excessive resources. It's kind of like riding to work every day on a tractor. True, you can copy the large file to the hard drive in an attempt to achieve maximum performance, but having that be a necessity is certainly of no benefit to you. Therefore, although it's great to have this resolution for those times you need higher definition, I include a second scan in more normal resolutions for daily research and use on the bench.
The second scan is done in resolutions that vary depending on individual page content, but are never higher than needed to produce a useable quality, quickly navigable file that will do the job without consuming more time and resources than are needed.
On the CD you'll receive the large "very high resolution" file, plus the smaller, faster and often more useable text-searchable version. ALL original manual pages are supplied. Some vendors proudly advertise page counts and file sizes, but since those counts and sizes are very often artificially inflated with advertising, shareware beg screens and/or blank pages, we refrain from joining them and instead will tell you that these manuals are complete and are scanned in the specified resolutions.
repair--parts.com bears NO responsibility for this ad. Please report ads that do not follow our
rules (on front page).
Posted By: Alberto Ferrell
Contact: a.ferrell@repair--parts.com (Alberto Ferrell) (this is a temporary forwarding address).
