Honeywell L4006A1959 aquastat 40-180F (low temp)
For Sale: Honeywell L4006A1959 aquastat 40-180F (low temp)
Subject Honeywell L4006A1959 aquastat 40-180F (low temp)
Ad is submitted by poster:
L4006A1959 High or Low limit Aquastat Controller with 40 F to 180 F operating temperature and 2 F fixed differential
INCLUDES: 1-1/2 in. (38 mm) insulation and heat-conductive compound.
Aquastat® Controllers are immersion type devices for limiting or regulating the temperature of liquids in boilers, storage tanks, and other applications where temperature control is required.
• Totally enclosed Micro Switch™ snap-acting switches operate on temperature rise to setpoint.
• Visible control point scale and external adjustment screw permit easy setting.
• Horizontal or vertical insertion of the sensing element.
• Direct or well immersion of the sensing element.
• Models available for strap-on mounting.
• Remote bulb model may be used to sense air temperature in ducts and in outside air sensing applications.
• TRADELINE models include heat-conductive compound.
High or Low limit Aquastat Controller with 100 F to 240 F operating temperature and 2 F fixed differential
SPST, contacts break on temperature rise.
Operating Temperature Range (F)
Operating Temperature Range (C)
15.6A @ 120 Vac;7.8A @ 240 Vac
Maximum Ambient Temperature (F)
Maximum Ambient Temperature (C)
5 5/8 in. high x 2 in. wide x 2 1/8 in. deep
143 mm high x 51 mm wide x 54 mm deep
Horizontal or Vertical Mounting
Approvals, Underwriters Laboratories Inc
UL Component Recognized: File No. MP466, Vol. 6, Sec.1, Guide No. MBPR2
Approvals, Canadian Standards Association
Approvals, American Gas Association IAS
1 1/2 in. (38 mm) insulation and heat-conductive compound.
