Oz~unimat DB200 minimachine techniques operator manual
For Sale: Oz~unimat DB200 minimachine techniques operator manual
Subject Oz~unimat DB200 minimachine techniques operator manual
Ad is submitted by poster:
Handbook and Operator's Manual"
This is a reproduction, not a photocopy, of an original Unimat Miniature Machine Techniques Handbook and Operator's Manual. This manual is for the Unimat Model DB 200 pictured below.
Center punching, 8; centering, 8
Chucks, centering, 18; collets, 23; drill, 2, 21;
3-jaw, 2, 6, 7; 4-jaw, 18; reversing jaws, 6; special,
Circular saw, attachment, 27, 28; speeds, 39
Collet attachment, 23, truing (mounting), 18; collets, 23
Drilling, angle, 14; centering, 15; deep hole, 13;
hand, 4, 16; miniature hole, 10, 14; speeds, 39;
techniques, 10, 13; vertical,10, 12
Finishing techniques (see abrasives, buffing, grinding, polishing,
Flexible shaft, 31 (see buffing, drilling, polishing, sanding)
Grinding, angle, 16; bench, 15-17; guard, 32; safety,
32; speeds, 16, 39; surface, 4, 16; tool, 16
Headstock, alignment, 10; maintenance, 33; raising block, 2, 28-30
Jig saw attachment, 3, 26; speeds, 39
Machine, adjustments, 8, 9; vise, 19, 29
Maintenance, bed-ways, 9, 15; lathe parts, 33; live center, 30; spindle, 33
Milling, 2, 19, 20; speeds, 39; table, 2, 19, 20
Parts, replacement list, 37, 38
Polishing arbor, 3, 32; preparations,32, (see abrasives, buffing)
Safety, 16, 32, 33; goggles, 36
Sanding, abrasive, 32; disc, 29; cement, 29
Sawing, circular, 27, 28; jig, 3, 26; speeds, 39; machine, 29
Slow speed attachment, 24, 25, 39
Steady, for wood, 30, rest, 31
Threading, attachment, 4, 24, 25; charts, 25;
die, 33; patterns, 4, 24; speeds, 39; tap, 12
Tools, cutting, 8, 9; sharpening, 4, 16;
Turning, 2; faceplate, 12; metal, 7; speeds, 39;
turning to size, 9; wood turning, 31-33
Wood turning, 29-33; chisels, 29-30; finishing, 30
I have collected this information for many years and have found the information they contain to be priceless in using and setting up the machines properly. I believe this manual will be a valuable resource of knowledge that will provide a lot of helpful information that is often hard to find. My manuals are not photocopies. I maintain a high standard of quality in my reproductions. Most of the manuals I reproduce look better than their originals. I have professionally digitally edited every page, and removed stains, wrinkles and handwriting. All of the manuals are printed on thick white paper to withstand shop wear and tear; they are then comb bound with heavy cover pages so they lie flat on the workbench.
Be sure to add my store to your favorites list!
I am adding new manuals all the time.
PLEASE READ the return policy and COMPLETE description of the manual.
Because of the nature of this product, I do not accept any returns or exchanges
under any circumstances. If you have any questions, email me or send me a picture first. I
