New uei phoenix i hvac/r clamp meter DL269
For Sale: New uei phoenix i hvac/r clamp meter DL269
Subject New uei phoenix i hvac/r clamp meter DL269
Ad is submitted by poster:
New UEi Phoenix I HVAC/R Clamp Meter DL269
Brand New with Full Factory Warranty
Visit My Store ,Check out my other items! for More Professional Test Tools
The DL269 Phoenix series offers the highest combination of functions, features, and safety offered in a meter today. Combined with The Hook extended clamp head, no contractor will have to compromise their safety, efficiency, or comfort.
* Detachable clamp head
* 750V AC / 1000V DC
* 40M Resistance / Continuity
* 4000 F Capacitance
* Frequency / Duty Cycle
* MIN / MAX display
* Large display with backlight
* Test lead storage
* Test lead holder on clamp head
* Three year limited warranty
AC Amps Measurement - Jaw input (45Hz to 400Hz)
Range Resolution Accuracy Overload Protection
45Hz to 400Hz True RMS (Crest factor <3:1)
DC Low Amps Measurement (test lead input)
Range Resolution Accuracy Overload Protection
400µA 0.01µA ±1.2% +3 dgts 2000µA / 600V
AC Low Amps Measurement (test lead input, 45Hz to 400Hz)
Range Resolution Accuracy Overload Protection
400µA 0.01µA ±2.0% +5 dgts 2000µA / 600V
45Hz to 400Hz True RMS (Crest factor <3:1)
Range Resolution Accuracy Overload Protection
400mV 0.1mV ±0.5% +4 dgts 600V
AC Volts Measurement (45Hz to 400Hz)
Range Resolution Accuracy Overload Protection
45Hz to 1KHz True RMS (Crest factor <3:1)
Range Resolution Accuracy Overload Protection
400 Ohms 100m Ohms±1.0% +4 dgts 600V
40M Ohms 10k Ohms±2.0% +4 dgts
Range Open Circuit Voltage Test Current (typical) Overload Protection
Range Resolution Accuracy Overload Protection
40nF 0.01nF ±3.5% +6 dgts 600V
Range Resolution Accuracy Overload Protection
15° to 752°F 0.1°F ±1.0% +3.6°F
-9° to 400°C 0.1°C ±1.0% +2.0°C
Range Resolution Accuracy Overload Protection
9.999Hz 0.001Hz ±0.1% +4 dgts 600V
Minimum frequency: 0.5Hz, DC V offset should be zero
Range Accuracy Overload Protection
01. to 99.9% ±(0.2% per kHz +0.1%) +5 count 600V
0.5Hz to 100kHz (pulsewidth > 2usec)
Open Circuit voltage <2.7V Overload Protection
Threshold Approximately <20 Ohms 600V
Complete User Manual & Data Sheet
Optional Accessories for DL269- CH2 The HOOK
Be sure to add me to your favorites list!
Money orders and cashier checks are accepted. NO PERSONAL CHECKS!
All Texas residents will be charged 8.25% sales tax during the checkout process.
