Tektronix SG502 Service/Ops Manual in both Very High and in Standard Resolution PDF on CD
Why settle for just one resolution? You get them both!
For High Res page samples from this specific manual, click HERE.
(No need to "email for samples," so no need to worry about getting sold to a SPAM list!)
(Please read FAQ or "About Me" Page)
Includes not only the Tektronix Semiconductor Parts Catalog, plus an interesting and informative Articles PDF, plus a fully bookmarked, hyperlinked and text-searchable scan of the entire "TM500 Rear Interface Data Book" and the publication "Suggested Power Supply Circuits for The TM500 Blank Plug-In Kit", but you also get the manuals for the TM501, TM-503, TM504, TM506, TM515 and TM5006 Power Modules, all at no additional charge!
This manual covers the Tektronix SG502 plugin for the TM500 Series Power Modules. It is scanned from the original manufacturer's manual. The scans came out well, and all information available in the original manual (Tektronix part number 070-1430-01, with changes to Feb '79) is available here.
Two PDFs of the manual are provided, in two resolutions. One is:
Text with Drawings at 600dpi black and white
Schematics at 600dpi black and white
Text with photos at 600dpi grayscale with contrast adjusted
Schematics, board overlays that have color notes at 600dpi 256 colors
This resolution looks nice, but for many purposes uses excessive resources. You can copy the large file to the hard drive in an attempt to achieve maximum performance, but having that be a necessity is certainly of no benefit to you. Therefore, although it's great to have this resolution for those times you need higher definition, we include a second scan in standard resolutions for daily research and use on the bench.
The second scan is done in resolutions that vary depending on individual page content, but are never higher than needed to produce a useable quality, quickly navigable file that will do the job without consuming more time and resources than are needed.
On the CD you'll receive the large "very high resolution" file, plus the smaller, faster and often more useable text-searchable version. ALL original manual pages are supplied. Some vendors proudly advertise page counts and file sizes, but since those counts and sizes are very often artificially inflated with advertising and/or blank pages, we refrain from joining them and instead assure you that these manuals are complete and are scanned in the specified resolutions.
