8" SURFACE GRINDER, Gallmeyer & Livingston 28
8" SURFACE GRINDER, Gallmeyer & Livingston 28
8" X 24" GALLMEYER & LIVINGSTON "GRAND RAPIDS"
w/AUTOMATIC INCREMENTAL DOWNFEED
MODEL: 280 S/N: 280292 NEW: 1980
HYDRAULIC TABLE TRAVEL, LONGITUDINAL .......... 29-1/2"
HYDRAULIC TABLE TRAVEL, CROSS .................. 9-1/4"
WORKING SURFACE OF TABLE ..................... 8" X 24"
WHEEL SIZE ................... 10" DIA. x 1"W x 3" BORE
SPINDLE SPEEDS (2) .................. 2,300 & 3,000 RPM
LONGITUDINAL TABLE SPEEDS ............... 3" - 150" IPM
AUTO CROSS FEED TO TABLE PER STROKE ..... 0.01" TO 1/2"
CONTINUOUS CROSS SPEED ....................... 120" IPM
AUTO INCREMENTAL DOWNFEED RATE ............ 0.0001" TO .001"
VERTICAL MOVEMENT OF WHEELHEAD .................... 16"
MAXIMUM DISTANCE FROM WHEEL TO TABLE (8" WHEEL) ... 15"
APPROXIMATE FLOOR SPACE ................... 101"W X 58"D
APPROXIMATE WEIGHT .......................... 4,650 LBS
AUTOMATIC INCREMENTAL DOWNFEED PER TABLE & SADDLE REVERSAL.
AUTO INCREMENTS FROM 0.0001" TO .001" PER REVERSAL.
WHEEL RETRACTS & TABLE PARKS @ COMPLETION OF AUTO IDF CYCLE.
HYDRAULIC LONGITUDINAL AND CROSS FEEDS
8" X 24" O.S WALKER FINE DIVISION ELECTRO-MAGNETIC CHUCK
O.S. WALKER VARIABLE HOLD NEUTROFIER CONTROL
COOLANT SYSTEM W/TANK/PUMP/SPLASH GUARDS
1.5 HP 3/60/220-440 VOLT HYDRAULIC SYSTEM MOTOR
2 HP 3/60/220-440 VOLT SPINDLE DRIVE
*** EXCELLENT, VERY CLEAN CONDITION & APPEARANCE ***
** INSPECT UNDER POWER IN OUR HARRISON, N.J. WAREHOUSE **
Click Here For More Gallmeyer & Livingston Machines
Click Here For More Grinders, Lappers & Hones - SURFACE GRINDERS(s)
Call Andy at (***) 873-6224 ext 7600
Call Alex at (***) 873-6224 ext 7613
Finance This Equipment For Your Business - Click Here
Finance Equipment For Your Business - Click Here
* Machinery Values is one of the world's largest machinery dealers, in business since 1971.
* New machines are covered under their own warrantees. Details of each warranty can be found within the quotation for all new machines.
* Most items in our store are located in our warehouse in Harrison, New Jersey - about 9 miles from New York City. You may inspect any item prior to purchase, under power in most cases, simply by calling and arranging an inspection. There is no charge for this.
