New bench multimeter true rms pc-link mastech MS8050
For Sale: New bench multimeter true rms pc-link mastech MS8050
Subject New bench multimeter true rms pc-link mastech MS8050
Ad is submitted by poster:
High Accuracy Bench Multimeter Mastech MS8050
MS8050 is a bench model DMM product that has high accuracy and high stability. Containing a 24 bits A/D converter and being controlled by a single-chip computer, it can operate for several ten measurement functions. It’s five digits can count up to 5300. Not only DC, AC RMS, but DC and AC mixture signal’s RMS can be measured for 1000V or 10A. The resolution of DCV is 1uV and the frequency band of voltage or current is about 20kHZ, which is sufficient for most electric measurement . MS8050 is also a frequency counter, which can test pulse frequency above 2MHZ or linear frequency above 200kHZ, including the frequency of current. The measurement of 50M ohm resistor,5000uF capacitor, and maximum/minimum value, average value, relative value, power DB, diode, continuity are often useful for engineers. It has a memory function up to 30 full screen for saving test data, has a color fluorescent double digital display screen. MS8050 is controlled and calibrated by software, non adjustable device, so it’s stability for long time is guaranteed. The meter has a light-coupling RS-232C interface and a computer software, can display, draw, record all test processes on a computer. The graphic software has an exclusive dynamic scale, which can describe very small changes of electric parameters. MS8050 together with a computer becomes a very useful measurement recorder. The protection functions against some error operations get it’s safety characteristic guaranteed. It is the best selection for factories, science research organizations, and laboratories in universities.
ACV and DCV measurements reach up to 1000V
DC measurement accuracy reaches up to 0.03
0.1 Ω resistance and 1 µ V voltage resolution
Voltage/Current Linear frequency measurement
Logic frequency/duty cycle measurement
Capacitance measurement from 0.01 nF to 5000µ F
AC/AC + DC true RMS/dBm measurement
Max/min/max-min value, relative value, average value measurement
RS-232C interface and PC Windows Software
Color fluorescent double display
Insulating performance reaching 1000V CATII
ACD/DCV + ACV: 50mV/500mV/5V/50V/500V/1000V ±0.5
DCV: 50mV/500mV/5V/50V/500V/1000V ±0.03
AC Current/DC Current + AC Current: 500 µ A/5000µ A/50mA/500mA/5A±0.75, 10A ±1.5
DC Current: 500µ A/5000µ A/500mA/5A/10A±0.15
Resistance: 500Ω/5k Ω /50K Ω /500K Ω /5M Ω /±0.1, 50M Ω±0.5
Capacitance: 50nF/500nF/5µ F/50µ F±1,500µ F/5000µ F±2
Duty Cycle: 5Hz ~500kHz, Range: 10~90
Logic Frequency: 5Hz~2MHz±0.006, Vpp 2 ~ 5V Square Wave
Linear Frequency: 10Hz ~ 200KHz±0.006, Sensitivity: lowest 4mV
Memory function : 30 full screen
Display: VFD Size 140mm X 40mm
Size: 13.8 X 9.8 X 3.9 inch (350 X 250 X 100 mm)
repair--parts.com bears NO responsibility for this ad. Please report ads that do not follow our
rules (on front page).
Posted By: Jay Levine
Contact: J_levine@repair--parts.com (Jay Levine) (this is a temporary forwarding address).
