1992 BRIDGEPORT 9" x 48" CNC EZ TRAK MILLING MACHINE
We are so confident in this unit that we are offering a full return freight paid money back guarantee on this if not completely satisfied!!!
Bridgeport CNC 2 Axis Vertical Milling Machine in great condition!
Made in the USA by Bridgeport Machines Inc. of Bridgeport, Connecticut.
In shop after shop all over the entire world the Bridgeport Milling Machine has been the basic machine tool for over thirty years.Its performance and economy are surpassed only by its versatility, for this compact machine can perform almost every machining operation required by the average shop.With standard attachments the Bridgeport can be used for vertical and horizontal milling, drilling, boring, straddle and cam milling, cherrying, fly cutting, profiling, reaming and slotting.By using special attachments and accessories the range of jobs accomplished by a Bridgeport can be extended to include three dimensional duplicating and tracing. In actuality, the capability of the Bridgeport is limited only by the imagination of the operator.Bridgeport Machines are sold nationally through a network of representatives and machine tool distributors, who are unusually skilled in the techniques of modern machining and parts processing. There's a Bridgeport representative in your area ready to provide you with prompt efficient service.
* Proven resale value! High demand caused many used Series I standards to sell for more than their original purchase price.
* Versatile-totally interchangeable parts. You choice of a full line of high productivity accessories and heads.
* Full support. Bridgeport stands behind every machine with nationwide parts and service, and application engineering support.
* Patented flow-through air cooling on 2J head prolongs bearing life and prevents expansion caused by heat build-up.
* Secure tools from 1/8" to 3/4" in a R8 collet.
* A quick adjustment micrometer nut allows rapid adjustment of the quill for long moves and can also be adjusted for fine positioning of .001".
* Sturdy, coreless cast table, heavily ribbed for strength.
* Precision ways on column, knee and table. Tapered, hand-scraped gibs, hand-fitted for long life accuracy. Locking clamps let you mill mild steel at 2 cu. in./min. with minimum vibration. One piece column and base with extra ribs and webs.
Infinitely Variable Speeds
Height Above Floor: 47 1/4"Travels:
Table Travel (X-Axis): 30"
Saddle Travel (Y-Axis): 12"
Throat Distance: 6.75"(min.) / 18.75" (max.)
Table to Spindle Nose: 2.5" (min.) / 18.25" (max.)
Quill Feed: 0.0015 / 0.003 / 0.006 in./rev
Low (infinitely variable): 60-500 rpm
High (infinitely variable): 500-4,200 rpmHead Adjustments:
Head Cant (forward/back): 45 degrees
Head Tilt (side to side): 90 degrees
Head Swivel (side to side): 360 degreesCapacities:
Drilling Capacity (Manual): 3/4"
Drilling Capacity (Power): 3/8"
Milling Capacity (mild steel): 2 cu. in./min.
Boring Range (mild steel): 6" diaMilling Feed Rate:
Standard: 3/4-35 ipm Motor:
Horsepower (Continuous / 30 min.): 2 / 3
Electrical: 220 Volt, Three Phase
Overall Dimensions: 70" x 59" x 84" tall.Comes as shown in pictures.
Use this Form to obtain a Freight Quote on a flat bed Trailer.
