South bend 9"-24" lathe parts manual series o,n,r,t,&jr
For Sale: South bend 9"-24" lathe parts manual series o,n,r,t,&jr
Subject South bend 9"-24" lathe parts manual series o,n,r,t,&jr
Ad is submitted by poster:
This is a reproduction, not a photocopy, of an original 9"-24" Lathes Parts Manual, dated between 1906-50's. This manual is for the 9", 11",13", 14", 15", 16", and 16/14" lathes, series O, N, R, T, and "Junior". Because of its age this is a rare manual to find in this condition and is nearly a collectors item by itself. This manual is in perfect shape. If you have one of these lathes this manual has pictures of every part of the lathe. Don't forget to check out my other items!
Some of the lathes made for the time frame covered by this manual were made without gear boxes for threading, but some did have a gear box. Below is a picture of the gear box that was used in this time frame.
How to Order Replacement Parts.............................................................
Headstock...........................................................................................
Tailstock..................................................................................................
Apron "O"................................................................................................
Apron "N"................................................................................................
Apron "R & T".......................................................................................
Apron 9",11" Junior..................................................................................
Apron 8" Junior, 9" Toolmaker.................................................................
Saddle and Compound Rest "O & Junior"...............................................
Saddle and Compound Rest "N".............................................................
Saddle and Compound Rest "R & T"......................................................
Gear Box "O,N,R,T"..............................................................................
Change Gear "O,N,R,T, Junior"..............................................................
Countersharft "O,N,R,T, Junior" (Drive Before Electric Motors)..............
Horizontal Motor Drive...........................................................................
Underneath Motor Drive.........................................................................
Silent Motor Drive..................................................................................
Manual Title: SOUTH BEND 9"-24" Lathe Parts Manual Series O,N,R,T,&Jr
Gear box has one lever on top and bottom, and covers lathes without gear boxes.
Manual Title: SOUTH BEND 10L,13,14.5,16 40'-50's Lathe Part Manual
Gear box has one lever on top and bottom.
Manual Title: SOUTH BEND 10" 13" 14½" 16" & 16/24" Lathes Manual/Parts
Gear box has two levers on the bottom.
I have collected this information for many years and have found the information they contain to be priceless in using and setting up the machines properly. I believe this manual will be a valuable resource of knowledge that will provide a lot of helpful information that is often hard to find. My manuals are not photocopies. I maintain a high standard of quality in my reproductions. Most of the manuals I reproduce look better than their originals. I have professionally digitally edited every page, and removed stains, wrinkles and handwriting. All of the manuals are printed on thick white paper to withstand shop wear and tear; they are then comb bound with heavy cover pages so they lie flat on the workbench.
Be sure to add me to your favorites list!
I am adding new manuals all the time.
PLEASE READ the return policy and COMPLETE description of the manual.
Because of the nature of this product, I do not accept any returns or exchanges
under any circumstances. If you have any questions email me or send me a picture first. I
