Industrial inspection zoom microscope 7~90X ccd adapter
For Sale: Industrial inspection zoom microscope 7~90X ccd adapter
Subject Industrial inspection zoom microscope 7~90X ccd adapter
Ad is submitted by poster:
Industrial Inspection Monocular Microscope
Find it later under "Favorites" menu in your browser.
* Plug and see, no special knowledge needed
* Ready to connect to CCD digital camera
* Zoom lenses 7x~90x, crystal clear at any point
* Long working distance allow enough lighting options
* Brightness adjustable incident and transmitted lights
* Sharp stereo erect images over a wide field view
* Product GS and CE approved
* Manufacturer in business 30+ years
* Eyepieces: wide field WF10X & WF20X
* Total magnification:7x~90x
* Objective zoom ratio: 1:6.5 (0.7x~4.5x)
* Working distance: 3-1/2" (90mm).
* Incident (upper) illuminator: 6V/15W halogen with reflector, variable inclination
* Transmitted (lower) illuminator: 6V/20W halogen
* Easy illumination mode switch: [upper] or [lower] or [off]
* Variable intensity illumination
* Frosted glass stage plate: 3-3/4" (95mm) in diameter
* White/black plastic stage plate: 3-3/4" (95mm) in diameter
* Power supply: 110V/60Hz (US and Canada)
* Dimensions: 12-1/2" x 10-1/2" x 18" (32cm x 27cm x 46cm)
* Net weight: 10 lb 6oz (4.7kg)
* Monocular stereo zoom microscope (0.7x~4.5x)
* Adapter for CCD camera (camera sold separately)
* Type C standard mount adapter for industrial standard CCD cameras
* Black/white high quality plastic stage plate
* Power cord (US and Canada standard)
* Extra halogen bulb 6V/15W with reflector
Optional Parts and Accessories (sold separately):
* Gooseneck fiber cold light
* Mechanical stage for stereo microscope
* Spare halogen bulb 12V/15W with reflector
* Large sturdy base stand with ring light holder
Note: Before you purchase any parts or accessories, please check the Compatibility Table below.
please click the search button below (do not change the pre-entered search term)
Q: How do I select a microscope which fits my needs?
A: You may get some basic knowledge from our Purchase Guide
Q: I sent you an email but haven't got you answer for more than 24 hours.
A: This may be due to email spam filters or other restrictions. Please read this important message: About Communication
