Lodestar signal generator sg-4160B


For Sale: Lodestar signal generator sg-4160B


Subject Lodestar signal generator sg-4160B
Ad is submitted by poster: Lodestar Signal Generator SG-4160B
Light weight. Unit is used & in very good cosmetic condition
Frequency range: (up to 450MHz on 3'th harmonics)
RF output: 100mVrms, approx (up to 35MHz unloaded).
Output control: High-low switch and fine adjuster.
Modulation: INT. 1KHz (AM) 30% approx. EXT. 50Hz ~ 20KHz, at less than 1Vrms input.
Audio output: 1KHz, Min. 2 Vrms.
Crystal oscillator: For 1 ~ 15MHz crystal in type HC-6u holder (not included).
Power requirement: AC 115 / 230V, 50 / 60Hz Approx 3VA.
Dimensions & weight: 150 (H) x 250 (W) x 130 (D) mm. Approx 2.5kgs.
Wide frequency range: 100KHz ~ 150MHz.
With 1KHz oscillator in inner part for the purpose of modulation.
Of portable type, high stability
Local Pick up is also available at our office in Clayton South VIC 3169 with 24 Hrs Prior Notice.
