Wiedemann c-3000/q centrum turret punch
For Sale: Wiedemann c-3000/q centrum turret punch
Subject Wiedemann c-3000/q centrum turret punch
Ad is submitted by poster:
WIEDEMANN MODEL C-3000/Q CENTRUM TURRET PUNCH*
Capacity: 33 Ton
Maximum Sheet Thickness: 1/4"
Maximum Sheet Size: 49.25" x 78.8" (w/o Repositioning)
Maximum Sheet Size: 49.25" x 157.6" (with Repositioning)
Maximum Traverse: 60" Y - Axis
79" X - Axis
Turret Configuration: 40 Stations - (12) 1/2" Diameter; (12) 1"
Diameter; (5) 1.5" Diameter; (5) 2" Diameter; (2) 2.5" to 3"
Diameter; (2) 3.5" to 4" Diameter; (2) Auto-Index (2" Dia.)
Tooling Type: 114 (Auto-Index Stations - 112 Type)
Turret Speed: 30 RPM (Bi-Directional)
Maximum Hit Rate: 220/250 HPM (1" Increment Movement)
Hit Rate (Continuous Nibble Mode): 490 SPM
Maximum Table Traverse Speeds: X-Axis - 2500 IPM; Y-Axis - 2500 IPM
EQUIPPED WITH:
Fanuc Model OP-A CNC Control w/CRT
(2) Auto-Index Stations
Hydraulic Work Clamping
Hydraulic Clutch and Brake
Automatic Lubrication System
10 HP Main Drive Motor
(4) AC Servo Motor Drives
Approximate Overall Dimensions: 203" L-R x 167" F-B x 84" H
Approximate Weight: 24,000 Lbs.(HEIGHT W/TRANSF.: 115")
Serial Number: 319570 (New 1986)
P2 F.O.B. Elk Grove, IL - $ 89,500.00
* PRELIMINARY SPECIFICATIONS SUBJECT TO VERIFICATION
